A Trip to Mathematics: Part-I Logic

Tuesday, October 25th, 2011 13:34 / 5 Comments

About “A Trip To Mathematics”:

A Trip to Mathematics is an indefinitely long series, aimed on generally interested readers and other undergraduate students. This series will deal Basic Mathematics as well as Advanced Mathematics in very interactive manners. Each post of this series is kept small that reader be able to grasp concepts. Critics and suggestions are invited in form of comments.

What is Logic?

If mathematics is regarded as a language, then logic is its grammar.
In other words, logical precision has the same importance in mathematics as grammatical accuracy in a language. As linguistic grammar has sentences, statements— logic has them too. Let we discuss about Sentence &Statements, then we shall proceed to further logic .

Sentence & Statements

A sentence is a collection of some words, those together having some sense.

For example:

Math is a tough subject.
English is not a tough subject.
Math and English both are tough subjects.
Either Math or English is tough subject.
If Math is a tough subject, then English is also a tough subject.
Math is a tough subject, if and only if English is a tough subject.

Just have a quick look on above collections of words. Those are sentences, since they have some meaning too. First sentence is called Prime Sentence, i.e., sentence which either contains no connectives or, by choice, is regarded as “indivisible”. The five words

not

and

or

if …. then

if and only if

or their combinations are called ‘connectives‘. The sentences (all but first) are called composite sentences, i.e., a declarative sentence (statement) in which one or more connectives appear. Remember that there is no difference between a sentence and statement in general logic. In this series, sentences and statements would have the same meaning.

Connectives

not: A sentence which is modified by the word “not” is called the negation of the original sentence.
For example: “English is not a tough subject” is the negation of “English is a tough subject“. Also, “3 is not a prime” is the negation of “3 is a prime“. Always note that negation doesn’t really mean the converse of a sentence. For example, you can not write “English is a simple subject” as the negation of “English is a tough subject“.
In mathematical writings, symbols are often used for conciseness. The negation of sentences/statements is expressed by putting a slash (/) over that symbol which incorporates the principal verb in the statement.
For example: The statement $x=y$ (read ‘x is equal to y’) is negated as $x \ne y$ (read ‘x is not equal to y‘). Similarly, $x \notin A$ (read ‘x does not belong to set A‘) is the negation of $x \in A$ (read ‘x belongs to set A‘).
Statements are sometimes represented by symbols like p, q, r, s etc. With this notation there is a symbol, $\not$ or ¬ (read as ‘not’) for negation. For example if ‘p’ stands for the statement “Terence Tao is a professor” then $\not p$ [or ¬p] is read as ‘not p’ and states for “Terence Tao is not a professor.” Sometimes ~p is also used for the negation of p.
and: The word “and” is used to join two sentences to form a composite sentence which is called the conjunction of the two sentences. For example, the sentence “I am writing, and my sister is reading” is the conjunction of the two sentences: “I am writing” and “My sister is reading“. In ordinary language (English), words like “but, while” are used as approximate synonyms for “and“, however in math, we shall ignore possible differences in shades of meaning which might accompany the use of one in the place of the other. This allows us to write “I am writing but my sister is reading” having the same mathematical meaning as above.
The standard notation for conjunction is $\wedge$ , read as ‘and‘. If p and q are statements then their conjunction is denoted by $p \wedge q$ and is read as ‘p and q’.
or: A sentence formed by connecting two sentences with the word “or” is called the disjunction of the two sentences. For example, “Justin Bieber is a celebrity, or Sachin Tendulkar is a footballer.” is a disjunction of “Justin Bieber is a celebrity” and “Sachin Tendulkar is a footballer“.
Sometimes we put the word ‘either‘ before the first statement to make the disjunction sound nice, but it is not necessary to do so, so far as a logician is concerned. The symbolic notation for disjunction is $\vee$ read ‘or’. If p and q are two statements, their disjunction is represented by $p \vee q$ and read as p or q.

if….then: From two sentences we may construct one of the from “If . . . . . then . . .“; which is called a conditional sentence. The sentence immediately following IF is the antecedent, and the sentence immediately following THEN is the consequent. For example, “If 5 <6, 6<7, then 5<7” is a conditional sentence whith “5<6, 6<7” as antecedent and “5<7” as consequent. If p and q are antecedent and consequent sentences respectively, then the conditional sentence can be written as:

“If p then q”.

This can be mathematically represented as $p \Rightarrow q$ and is read as “p implies q” and the statement sometimes is also called implication statement. Several other ways are available to paraphrase implication statements including:

If p then q
p implies q
q follows from p
q is a logical consequence of p
p (is true) only if q (is true)
p is a sufficient condition for q
q is a necessary condition for p

If and Only If: The phrase “if and only if” (abbreviated as ‘iff‘) is used to obtain a bi-conditional sentence. For example, “A triangle is called a right angled triangle, if and only if one of its angles is 90°.” This sentence can be understood in either ways: “A triangle is called a right angled triangle if one of its angles is 90°” and “One of angles of a triangle is 90° if the triangle is right angled triangle.” This means that first prime sentence implies second prime sentence and second prime sentence implies first one. (This is why ‘iff’ is sometimes called double-implication.)

Another example is “A glass is half filled iff that glass is half empty.“

If p and q are two statements, then we regard the biconditional statement as “p if and only if q” or “p iff q” and mathematically represent by ” $p\iff q$ “. $\iff$ represents double implication and read as ‘if and only if’.

In the statement $p \iff q$ , the implication $p \Rightarrow q$ is called direct implication and the implication $q \Rightarrow p$ is called the converse implication of the statement.

Other terms in logic:

Stronger and Weaker Statements: A statement p is stronger than a statement q (or that q is weaker than p) if the implication statement $p \Rightarrow q$ is true.
Strictly Stronger and Strictly Weaker Statements: The word ‘stronger‘(or weaker) does not necessarily mean ‘strictly stronger‘ (or strictly weaker).
For example, every statement is stronger than itself, since $p \Rightarrow p$ . The apparent paradox here is purely linguistical. If we want to avoid it, we should replace the word stronger by the phrase ‘stronger than‘ or ‘possibly as strong as‘.

If $p \Rightarrow q$ is true but its converse is false ( $q \not \Rightarrow p$ ), then we say that p is strictly stronger than q (or that q is strictly weaker than p). For example it is easy to say that a given quadrilateral is a rhombus that to say it is a parallelogram. Another understandable example is that ” If a blog is hosted on WordPress.com, it is powered with WordPress software.” is true but ” If a blog is powered with WordPress software , it is hosted on WordPress.com” is not true.

Logical Approach

What exactly is the difference between a mathematician, a physicist and a layman?
Let us suppose they all start measuring the angles of hundreds of triangles of various shapes, find the sum in each case and keep a record.

Suppose the layman finds that with one or two exceptions the sum in each case comes out to be 180 degrees. He will ignore the exceptions and state ‘The sum of the three angles in a triangle is 180 degrees.’

A physicist will be more cautious in dealing the exceptional cases. He will examine then more carefully. If he finds that the sum in them some where 179 degrees to 181 degrees, say, then if will attribute the deviation to experimental errors. He will state a law – ‘The sum of the three angles of any triangle is 180 degrees.’ He will then watch happily as the rest of the world puts his law to test and finds that it holds good in thousands of different cases, until somebody comes up with a triangle in which the law fails miserably. The physicist now has to withdraw his law altogether or else to replace it by some other law which holds good in all the cases tried. Even this new law may have to be modified at a later date. And this will continue without end.

A mathematician will be the fussiest of all. If there is even a single exception, he will refrain from saying anything. Even when millions of triangles are tried without a single exception, he will not state it as a theorem that the sum of the three angles in ‘any’ triangle is 180 degrees. The reason is that there are infinitely many different types of triangles. To generalise from a million to infinity is as baseless to a mathematician as to generalise from one to a million. He will at the most make a conjecture and say that there is a ‘strong evidence’ suggesting that the conjecture is true.

The approach taken by the layman or the physicist is known as the inductive approach whereas the mathematician’s approach is called the deductive approach.

Inductive Approach

In inductive approach, we make a few observations and generalise. Exceptions are generally not counted in inductive approach.

Deductive Approach

In this approach, we deduce from something which is already proven.

Axioms or Postulates

Sometimes, when deducting theorems or conclusion from another theorems, we reach at a stage where a certain statement cannot be proved from any ‘other’ proved statement and must be taken for granted to be true, then such a statement is called an axiom or a postulate.
Each branch of mathematics has its own populates or axioms. For example, the most fundamental axiom of geometry is that infinitely many lines can be drawn passing through a single point. The whole beautiful structure of geometry is based on five or six such axioms and every theorem in geometry can be ultimately Deducted from these axioms.

Argument, Premises and Conclusion

An argument is really speaking nothing more than an implication statement. Its hypothesis consists of the conjunction of several statements, called premises. In giving an argument, its premises are first listed (in any order), then connecting all, a conclusion is given. Example of an argument:
Premises:   $p_1$          Every man is mortal.
$p_2$                               Ram is a man.
———————————————————————————-
Conclusion:                   $q$ Ram is mortal.

Symbolically, let us denote the premises of an argument by $p_1, p_2, \ldots , p_n$ and its conclusion by $q$ . Then the argument is the statement $(p_1 \wedge p_2 \wedge \ldots \wedge p_n) \Rightarrow q$ . If this implication is true, the argument is valid otherwise it is invalid.

To be continued……

Basic logic – connectives – NOT (gowers.wordpress.com)
Welcome to the Cambridge Mathematical Tripos (gowers.wordpress.com)

The problem of the Hundred Fowls

Saturday, October 1st, 2011 17:37 / Leave a Comment

This is a popular Chinese problem, on Linear Diophantine equations, which in wording seems as a puzzle or riddle. However, when used algebraic notations, it looks obvious. The problems states :

If a cock is worth 5 coins, a hen 3 coins, and three chickens together 1 coin, how many cocks, hens and chickens, totaling 100 in number, can be bought for 100 coins?

This puzzle in terms of algebraic equations can be written as $5x+3y+\frac{1}{3}z=100$ and $x+y+z=100$
where $x, y, z$ being the number of cocks, hens and chicks respectively.
We find that there are two equations with three unknown quantities. So eliminating one of the unknowns, by putting $z=100-x-y$ from second equation into first one such that $5x+3y+\frac{1}{3} (100-x-y)=100$
or, $15x+9y+100-x-y=300$
or, $14x+8y=200$
or, $7x+4y=100$ .
Which is a linear Diophantine equation (with only two unknown quantities).
The equation $7x+4y=100$ has the general solution [links to WolframAlpha] $x=4 t$ and $y=25-7t$ , so that $z=75+3t$ where $t$ is an arbitrary integer.
Now, since $x, y, z$ are the number of creatures, hence $x, y, z >0$ and thus $4t >0$ , $25-7t >0$ and $75+3t >0$ which imply that $0 < t < 3\frac{4}{7}$ . And because t must have integer values, we have $t=1,2,3$ . Which gives the following three solutions:

Values of $t$	No. Of cocks ( $x=4 t$ )	No. Of hens ( $y=25-7t$ )	No. Of chicks ( $z=75+3t$ )
1	4	18	78
2	8	11	81
3	12	4	84

So there are the three ways to chose the number of cocks, hens and chicken totaling 100 to buy for 100 coins.

Problem Sources:
Elementary Number Theory
David M. Burton, 2006
McGrawHill Publications

Wikipedia article on Diophantine Equations

Image Credit

How to Draw the Famous Batman Curve

Saturday, September 24th, 2011 16:41 / 3 Comments

The ellipse $\displaystyle \left( \frac{x}{7} \right)^{2} + \left( \frac{y}{3} \right)^{2} - 1 = 0$ looks like this:

ellipse

So the curve $\left( \frac{x}{7} \right)^{2}\sqrt{\frac{\left| \left| x \right|-3 \right|}{\left| x \right|-3}} + \left( \frac{y}{3} \right)^{2}\sqrt{\frac{\left| y+3\frac{\sqrt{33}}{7} \right|}{y+3\frac{\sqrt{33}}{7}}} - 1 = 0$ is the above ellipse, in the region where $|x|>3$ and $y > -3\sqrt{33}/7$ :

ellipse cut

That’s the first factor.
(more…)

Study Notes Announcements and more…

Thursday, September 22nd, 2011 19:12 / 2 Comments

Announcement

Hi all!
I know some friends, who don’t know what mathematics in real is, always blame me for the language of the blog. It is very complicated and detailed. I understand that it is. But MY DIGITAL NOTEBOOK is mainly prepared for my study and research on mathematical sciences. So, I don’t care about what people say (SAID) about the

A Torus

content and how many hits did my posts get. I feel happy in such a way that MY DIGITAL NOTEBOOK has satisfied me at its peak-est level. I would like to thank WordPress.com for their brilliant blogging tools and to my those friends, teachers and classmates who always encourage me about my passion. For me the most important thing is my study. More I learn, more I will go ahead. So, today (I mean tonight) I have decided to write some lecture-notes (say them study-notes, since I am not a lecturer) on MY DIGITAL NOTEBOOK. I have planned to write on Group Theory at first and then on Real Analysis. And this post is just to introduce you with some fundamental notations which will be used in those study-notes.

Notations

Conditionals and Operators
$r /; c$ : Relation $r$ holds under the condition $c$ .
$a=b$ : The expression $a$ is mathematically identical to $b$ .
$a \ne b$ : The expression a is mathematically different from $b$ .
$x > y$ : The quantity $x$ is greater than quantity $y$ .
$x \ge y$ : The quantity $x$ is greater than or equal to the quantity $y$ .
$x < y$ : The quantity $x$ is less than quantity $y$ .
$x \le y$ : The quantity $x$ is less than or equal to quantity $y$ .
$P := Q$ : Statement $P$ defines statement $Q$ .
$a \wedge b$ : a and b.
$a \vee b$ : a or b.
$\forall a$ : for all $a$ .
$\exists$ : [there] exists.
$\iff$ : If and only if.
Sets & Domains
$\{ a_1, a_2, \ldots, a_n \}$ : A finite set with some elements $a_1, a_2, \ldots, a_n$ .
$\{ a_1, a_2, \ldots, a_n \ldots \}$ : An infinite set with elements $a_1, a_2, \ldots$
$\mathrm{\{ listElement /; domainSpecification\}}$ : A sequence of elements `listElement` with some `domainSpecifications` in the set. For example, $\{ x : x=\frac{p}{q} /; p \in \mathbb{Z}, q \in \mathbb{N^+}\}$ $a \in A$ : $a$ is an element of the set A.
$a \notin A$ : a is not an element of the set A.
$x \in (a,b)$ : The number x lies within the specified interval $(a,b)$ .
$x \notin (a,b)$ : The number x does not belong to the specified interval $(a,b)$ . Standard Set Notations
$\mathbb{N}$ : the set of natural numbers $\{0, 1, 2, \ldots \}$
$\mathbb{N}^+$ : The set of positive natural numbers: $\{1, 2, 3, \ldots \}$
$\mathbb{Z}$ : The set of integers $\{ 0, \pm 1, \pm 2, \ldots\}$
$\mathbb{Q}$ : The set of rational numbers
$\mathbb{R}$ : The set of real numbers
$\mathbb{C}$ : The set of complex numbers
$\mathbb{P}$ : The set of prime numbers.
$\{ \}$ : The empty set.
$\{ A \otimes B \}$ : The ordered set of sets $A$ and $B$ .
$n!$ : Factorial of n: $n!=1\cdot 2 \cdot 3 \ldots (n-1) n /; n \in \mathbb{N}$

Other mathematical notations, constants and terms will be introduced as their need.

For Non-Mathematicians:
Don’t worry I have planned to post more fun. Let’s see how the time proceeds!

Using math symbols in wordpress pages and posts – LaTex (1) (etidhor.wordpress.com)
Do complex numbers really exist? (math.stackexchange.com)
LaTeX Typesetting – Basic Mathematics (r-bloggers.com)

Social Networks for Math Majors

Tuesday, September 13th, 2011 11:44 / 9 Comments

Math or Mathematics is not as difficult as it is thought to be. Mathematical Patterns, Structures, Geometry and its use in everyday life make it beautiful. ‘Math majors’ term generally include Math students, Math professors and researchers or Mathematicians. Internet has always been a tonic for learners and whole internet is supposed to be a social network, in which one shares and others read, one asks & others answer. There are thousands of social networks (and growing) where you enjoy your days, share fun etc. However there are only a few social (mathematical) networks which are completely focused on math and related sciences. But these are brilliantly good enough to demonstrate the wisdom of mathematicians. I have tried to list my favorite social networking websites on mathematics. Please have a read and give feedback in form of comments
Click On Images To Visit Corresponding Websites.

Math.Stack Exchange

Mathematics StackExchange Website

Mathematics Stack exchange is a website dedicated to all types of mathematical discussions. You can ask questions, give answers, comment on questions and vote for it. Registration is very easy and takes seconds. Depending on your work, you are given ‘reputations’. Depending upon some special works, you are also given some privileges.

This is a free, community driven Q&A for people studying math at any level and professionals in related fields. It is a part of the Stack Exchange network of Q&A websites, and it was created through the open democratic process defined at Stack Exchange Area 51. (more…)

Just another way to Multiply

Thursday, August 25th, 2011 18:30 / 13 Comments

Multiplication is probably the most important elementary operation in mathematics; even more important than usual addition. Every math-guy has its own style of multiplying numbers. But have you ever tried multiplicating by this way?
Exercise: $88 \times 45$ =?
Ans: as usual :- 3960 but I got this using a particular way:
88    45
176          22
352           11
704    5
1408    2
2816          1

Sum of left column=3960

Thus, $88 \times 45=3960$ (as usual).
You might be thinking that what did I do here. Okay, let we understand this method by illustrating another multiplication, of 48 with 35.

Step 1. Write the numbers in two separate columns.

$48 \ 35$

Step 2. Now, double the number in left column and half the number in right column such that the number in right column reduces to 1. If the number [remaining] in right column is odd, then leave the fractional part and only write integer part.

$48 \ 35 \\ 96 \ 17\\192 \ 8\\384 \ 4\\ 768 \ 2 \\ 1536 \ 1$

Step 3: Cancel out any number in the left column whose corresponding number in the right column is even.

48                       35
96                       17
192                      8
384                       4
768                       2
1536                      1

Step 4:Sum all the numbers in the left column which are not cancelled. This sum is the required product.

$=1680$

I agree this method of multiplying numbers is not easy and you’re not going to use this in your every day math. It’s a bit boring and very long way of multiplication. But you can use this way to tease your friends, teach juniors and can write this into your own NOTEBOOK for future understandings. Remember, knowing more is getting more in mathematics. [LOL] I don’t know who, silly else me, made this quote. Have Fun.

Do you multiply this way! (wpgaurav.wordpress.com)

A Problem on Infinite Sum and Recurrence Relations

Friday, March 18th, 2011 20:08 / Leave a Comment

Problem

Consider the infinite sum
$\mathbb{S} = \dfrac {a_0} {10^0} + \dfrac {a_1} {10^2} + \dfrac {a_2} {10^4} + .......$ where the sequence $\{a_n\}$ is defined by $a_0=a_1=1$ , and the recurrence relation $a_n=20a_{n-1} + 12 a_{n-2}$ for all positive integers $n \ge 2$ . If $\sqrt {\mathbb {S} }$ can be expressed in the form $\dfrac {a} {\sqrt{b}}$ where $a$ & $b$ are relatively prime positive integers. Determine the ordered pair $(a, \, b)$ .

Solution

As the recurrence relation states $a_n-20a_{n-1} - 12 a_{n-2} =0$ , we shall reform the infinite sum into the same pattern (have a deep look);
$\mathbb{S} - \dfrac {20 \mathbb{S} } {10^2} - \dfrac {12 \mathbb{S} } {10^4}$
$= ( \dfrac {a_0} {10^0} + \dfrac {a_1} {10^2} + \dfrac {a_2} {10^4} + \dfrac {a_3} {10^6} + .... )$ $- ( \dfrac {20a_0} {10^2} + \dfrac {20a_1} {10^4} + \dfrac {20a_2} {10^6} + \dfrac {20a_3} {10^8} + .... )$ $- ( \dfrac {12a_0} {10^4} + \dfrac {12a_1} {10^6} + \dfrac {12a_2} {10^8} + \dfrac {12a_3} {10^10} + .... )$

After Simplifying and arranging

$= \dfrac {a_0} {10^0} + \dfrac {a_1} {10^2} - \dfrac {20a_0} {10^2} + \dfrac {a_2 -20a_1-12a_0} {10^4} + \dfrac {a_3-20a_2-12a_1} {10^6} + \dfrac {a_4-20a_3-12a_2} {10^8} + . . . . . . \infty$
Now, as {the recurrence relation is}
$a_n-20a_{n-1}-12a_{n-2} =0$ for all $n \ge 2$ , all terms except first three are zero in R.H.S.
Hence we have,
$\mathbb{S} - \dfrac {20 \mathbb{S} } {10^2} - \dfrac {12 \mathbb{S} } {10^4} = \dfrac {a_0} {10^0} + \dfrac {a_1} {10^2} - \dfrac {20a_0} {10^2}$
and substituting $a_0 =a_1=1$ , we have
$\mathbb{S} - \dfrac {20 \mathbb{S} } {100} - \dfrac {12 \mathbb{S} } {10000}$
$= \dfrac {1} {1} + \dfrac {1} {100} - \dfrac {20} {100}$
or
$\dfrac {7988 \mathbb{S}} {10000} = \dfrac {81} {100}$
so,
$\mathbb{S} =2025/1997$
From the Problem,
$\sqrt {\mathbb{S}} = \sqrt{2025/1997} = 45/\sqrt{1997} =a/\sqrt{b}$
So, the desired ordered pair is $(a, b) = (45, 1997)$ .
